The Alpha G-1200 Electric Over Hydraulic (EOH) Brake Actuator by Deutsche Hydrapro is engineered for heavy-duty drum brake trailers requiring more power and instant response. Delivering 1,000 PSI in just 0.118 seconds and supporting up to 1,200 PSI, this actuator is ideal for over-8K axle capacity configurations. It features a sealed IP67-rated anodized housing, built-in compatibility adapter, and flexible brake line routing—all packed into a sleek, compact unit built for harsh environments.

Detailed Information:

Fitting:

Designed for high-capacity drum brake trailers with axle ratings above 8,000 lbs. Supports flexible 360° brake line routing and simplified mounting on utility, equipment, livestock, and cargo trailers.

Features:

• Boosted Power: Rated for 1,200 PSI, perfect for over-8K drum brake systems.
• Fast Reaction Time: Achieves 1,000 PSI in just 0.118 seconds for immediate braking performance.
• Built-in Adapter: Internal compatibility hardware means no external modules needed.
• Rugged & Weatherproof: Anodized housing with sealed tank and IP67-rated circuit board protection.
• Flexible Mounting: Compact size with 360° port orientation for tight-space installations.

Interchangeable Part Numbers:

• G1200-Alpha
• G1200-A
• G1200

Product Overview:

The EOH Brake Actuator – 1200 PSI – Alpha G-1200 by Deutsche Hydrapro is the ultimate upgrade for drum brake systems demanding higher hydraulic pressure and fast response. With smart design features, IP67-rated protection, and powerful internal electronics, this actuator provides elite braking control in a sleek and durable format—backed by a 2-year warranty and ready for whatever the road throws at you.
