EOH Brake Actuator – 1000 PSI – Alpha G-1000 | DHDPR
EOH Brake Actuator – 1000 PSI – Alpha G-1000 | DHDPR
The Alpha G-1000 Electric Over Hydraulic (EOH) Brake Actuator from Deutsche Hydrapro delivers industry-leading response time and rugged durability in a compact design. Built for drum brake systems on axles rated up to 8,000 lbs, this actuator reaches full 1,000 PSI braking pressure in just 0.118 seconds. Encased in a corrosion-resistant anodized housing and equipped with sealed electronics, it's engineered for tough towing environments and long-lasting performance.
Detailed Information:
| Application | Drum Brakes (Up to 8K Axles) |
|---|---|
| PSI Rating | 1,000 PSI (0.118 sec response) |
| Voltage | 12V DC (Min. 30A feed) |
| Current Draw | 18–24 Amps |
| Fluid Type | DOT 3 / DOT 4 (No DOT 4+) |
| Fluid Capacity | 15.7 oz |
| Hydraulic Port | 3/16" Inverted Flare |
| Dimensions | 10" L x 6" H x 3.6"/1.7" W |
Fitting:
Compatible with trailers using drum brake systems on 1–3 axles. Ideal for livestock, utility, equipment, and general cargo trailers operating in rugged or coastal conditions.
Features:
- Rapid Response Time: Delivers full braking power in under 0.12 seconds.
- Weatherproof Build: Sealed IP67-rated electronics with conformal-coated circuitry for harsh environments.
- Compact Versatility: Small form factor with 360° brake line connection flexibility.
- Corrosion Resistance: Anodized T6 alloy housing withstands saltwater and road abuse.
- Low Maintenance: Minimal moving parts and sealed design extend product lifespan.
Interchangeable Part Numbers:
- G1000-Alpha
- G-1000
Product Overview:
The EOH Brake Actuator – 1000 PSI – Alpha G-1000 by Deutsche Hydrapro is engineered for trailers demanding precision, speed, and durability. With lightning-fast response, compact footprint, and rugged construction, it ensures optimal braking performance for any heavy-duty drum brake setup. Assembled in Australia and backed by a 2-year warranty, this actuator offers reliable stopping power where it matters most.
- Product type: Disc Brakes & Hydraulic Components
