This 6-hole adjustable channel bracket provides a secure and flexible mounting base for couplers, lunette rings, or clevis mounts. Designed for heavy-duty trailers, it offers 5 vertical adjustment positions across 8" of travel. Built from raw steel with a light oil coating, it's easy to weld and customize as needed.
Detailed Information:
| Mounting Holes | 6 Holes (3 per side) |
|---|---|
| Adjustment Positions | 5 Vertical Positions |
| Vertical Adjustment Range | 8" |
| Hole Diameter | 5/8" |
| Hole Spacing (Center to Center) | 2" |
| Inside Width | 3" |
| Overall Height | 11.5" |
| Thickness | 2-1/4" |
| Weight Capacity | 14,000 lbs |
Fitting:
Accepts most height-adjustable couplers, lunette rings, or clevis mounts with 2" hole spacing and 5/8" diameter mounting hardware. The 3" internal width is compatible with standard coupler widths. Weld-on installation recommended for structural integrity.
Features:
- Height Versatility: Offers 8" of vertical range for adjusting coupler height to match your tow vehicle.
- Heavy-Duty Design: Built from strong steel for high-load applications up to 14,000 lbs.
- Raw Weld-Ready Finish: Coated with light oil to prevent rust before welding.
- Universal Mount: Works with ball couplers, lunette rings, and clevis hitches.
Interchangeable Part Numbers:
- A-CB6
- CTA-CB6
- 8978XL (Replaces Redline)
Product Overview:
The 6-Hole Adjustable Channel Bracket provides a strong, weld-on mounting solution for trailer couplers requiring height adjustment. Perfect for equipment, dump, and utility trailers, this bracket ensures compatibility, strength, and long-term reliability on the road or job site.
- Product type: Couplers & Jacks
