BK99-865-58 - Drum Kit – 7K – Pre-Greased – 5/8 Studs | MT
BK99-865-58 - Drum Kit – 7K – Pre-Greased – 5/8 Studs | MT
The 7,000 lbs PRE-GREASED Drum Kit - 5/8 by MT is the go-to solution for trailers with 7,000 lb axles using a #42 spindle. Ideal for fast, reliable servicing, this complete kit supports 12" x 2" brake assemblies and includes all key hardware for direct mounting. Pre-lubed and boxed for convenience, it’s built to handle the demands of commercial and recreational trailers alike—ensuring safe, long-lasting wheel performance on the road.
Detailed Information:
| Axle Capacity | 7,000 lbs |
|---|---|
| Hub Capacity | 3,500 lbs |
| Bolt Pattern | 8 on 6-1/2″ |
| Wheel Size Compatibility | 16″, 17.5″ |
| Drum Dimensions | 12″ Diameter x 2″ Width |
| Stud Size | 5/8″ |
| Construction | Durable Steel |
Included Components:
- Inner Bearing: 25580 (ID: 1.75″)
- Outer Bearing: 14125A (ID: 1.25″)
- Inner Race: 22520
- Outer Race: 14276
- Grease Seal: #42 (ID: 2.25″ / OD: 3.376″)
- Pre-Greased Drum Assembly
- Dust Cap
- 5/8″ Studs
- 5/8″ Lug Nuts
- Spindle Nut
- Flat Washer
- D Washer
- Tang Washer
- Cotter Pin
Features:
- Fully Assembled & Greased: Inner bearing and seal pre-installed; outer bearing pre-greased
- Heavy-Duty Compatibility: Works with Dexter, AL-KO, Lippert, Rockwell, and Besser Pro trailer axles
- Brake Versatility: Compatible with both electric and hydraulic 12" x 2" brake systems
- Built to Last: High-quality steel construction ensures longevity under demanding conditions
- Common Trailer Applications: Utility trailers, flatbeds, equipment trailers, campers, horse trailers & more
Interchangeable Part Numbers:
- BK99-865-58
Product Overview:
The 7,000 lbs PRE-GREASED Drum Kit - 5/8 by MT is the go-to solution for trailers with 7,000 lb axles using a #42 spindle. Ideal for fast, reliable servicing, this complete kit supports 12" x 2" brake assemblies and includes all key hardware for direct mounting. Pre-lubed and boxed for convenience, it’s built to handle the demands of commercial and recreational trailers alike—ensuring safe, long-lasting wheel performance on the road.
- Product type: Drums & Hubs
