This adjustable axle spring seat is designed for use with 5" round tube axles rated 10,000 lbs. It ensures precise alignment of leaf springs and provides secure axle positioning, making it an essential part of heavy-duty trailer suspension systems.

Detailed Information:

Fitting:

Weld-on installation for 5" round tube axles. Two spring seats are required per axle. Designed to work with leaf springs featuring a raised center knob for added retention.

Features:

• Adjustable Support: Provides flexibility in axle placement for proper suspension geometry.
• Secure Spring Positioning: Cutout surrounds the spring knob to prevent shifting or rotation.
• Heavy-Duty Construction: Built from robust steel to handle high-load demands.
• Enhanced Load Distribution: Promotes balance and improved towing performance.
• Tailored Fit: Optimized for Dexter axles with 5" diameter tubes.

Interchangeable Part Numbers:

• 003-173-032
• 003-173-01
• 20-0031730311
• 1086

Product Overview:

The Adjustable Axle Spring Seat – For 5" Tube | DXT is a premium suspension component built for heavy-duty trailer axles. It delivers secure leaf spring support and prevents unwanted movement under load, extending the life of the suspension system. Ideal for high-capacity trailers requiring precise and durable axle alignment.
