77-12-1 - 7K Electric Brake – Manual Adjust – Left Side | MT
77-12-1 - 7K Electric Brake – Manual Adjust – Left Side | MT
This left-side manual adjust electric brake assembly is built for heavy-duty trailers with axles rated from 5,200 to 7,000 lbs. Measuring 12" x 2", it offers precise and consistent braking performance with simple manual adjustments—ideal for maintenance-focused setups and long-haul reliability.
Detailed Information:
| Axle Capacity | 5,200 – 7,000 lbs |
|---|---|
| Hub Capacity | Fits 12" x 2" drums |
| Bolt Pattern | 5-bolt |
| Wheel Compatibility | 14.5", 15", 16", 16.5" |
| Races | Not included |
| Studs | Not applicable |
| Coating | Corrosion-resistant coating |
Fitting:
Designed for the left (driver) side of trailer axles using electric drum brakes. Mounts using a standard 5-bolt brake flange. Compatible with most industry-standard hub-and-drum setups including Dexter, Lippert, and AL-KO.
Features:
- Manual Adjust System: Offers fine-tuned braking through standard access ports.
- Field-Tested Magnets: Each unit tested for optimal pull force and electrical conductivity.
- Rugged Build Quality: Built for high-load conditions and repeated stops.
- Easy Drop-In Replacement: Compatible with OEM Dexter and MAT assemblies.
- Rust-Resistant Finish: Extends product lifespan and resists harsh road environments.
Interchangeable Part Numbers:
- DEXTER K23-106-00
- DEXTER K23-180-00
- MAT 77-12-1
- MAT 77-12-01
Product Overview:
This 7K-rated left-hand electric brake assembly from MAT is built for tough trailer applications. It replaces a wide range of Dexter and MAT units, ensuring hassle-free upgrades or replacements. With 100% tested magnets and corrosion-resistant construction, it's ready to deliver steady braking on the road.
- Product type: Brakes
